Block for Falcon Tubes

From $255.00 (Ex GST)

  •  Fits 15 mL and 50 mL Falcon tube heating workflows
  • 12 hole and 4 hole formats support different tube capacities
  • Conical hole base supports suitable Falcon tube placement
  • Black anodised aluminium construction supports rapid heat transfer
  • Thermometer reference hole included for temperature reference use
  • Evaporation manifolds available to suit compatible applications

View More

SKU: LC-30-FB50 Categories: ,

Description

Dry Block Heater Blocks for Falcon tubes, when used with a dry block heater, are used for sample preservation and reaction work, enzyme digestions, enzyme activity studies, DNA amplification, incubation and activation of cultures, melting and boiling point work, and nucleic acid hybridisations.

This combined Falcon tube block range includes formats for 12 x 15 mL Falcon tubes and 4 x 50 mL Falcon tubes. Each block is designed with a conical hole base type, chemical-resistant black anodised finish, thermometer reference hole, compatibility with many other dry block heater brands, and evaporation manifolds available to suit.

Each block measures L95 x W75 x H50 mm and is made from solid black anodised aluminium. The solid construction supports rapid heat transfer and fast block heat-up when used in a dry block heater, while excellent temperature uniformity supports reliable laboratory heating performance across compatible Falcon tube formats.

These blocks are designed to suit dry block heaters and can also fit many other brands of dry block heaters. Customised blocks are also available upon request when a standard block is unsuitable, with 50 mm, 80 mm, and 100 mm depths available to suit a wide range of applications. Also known as a Falcon block, Falcon tube block, dry bath block, constant temperature block, or test tube block.

Specifications

  • Tube formats: 12 x 15 mL Falcon tubes and 4 x 50 mL Falcon tubes
  • Number of holes: 12 and 4
  • Hole width: 17 mm at opening and 29.2 mm
  • Hole depth: 45 mm
  • Hole base type: Conical
  • Block dimensions: L95 x W75 x H50 mm
  • Thermometer reference hole: Yes
  • Material: Black anodised aluminium
  • Finish: Chemical-resistant black anodised finish
  • Heater compatibility: Designed to suit dry block heaters and many other dry block heater brands
  • Evaporation manifolds: Available to suit
  • Custom block depths available: 50 mm, 80 mm and 100 mm upon request
Item Code No. of Holes Hole Width Hole Depth Hole base type Block dimensions Thermometer reference hole
LC-30-FB15 12 17mm 45mm Conical L95 x W75 x H50mm Yes
LC-30-FB50 4 29.2mm 45mm Conical L95 x W75 x H50mm Yes
