Pocket Nitrate Ion Meter, Single-Drop On-Site Testing

Description

LAQUAtwin NO3-11 Pocket Nitrate Meter is designed for direct nitrate testing from very small sample volumes, making it a practical choice for portable water quality testing, fieldwork, and routine laboratory use. HORIBA’s compact design integrates the electrode, display, and sample container into one handheld meter, allowing simple and effective on-site testing from a single drop. With a minimum sample volume of 0.3 mL, or 0.05 mL when used with Sampling Sheet B, this meter helps reduce sample waste while supporting fast and convenient measurement.

This compact nitrate meter measures both nitrate, NO3-, and nitrate-nitrogen, NO3-N, giving users greater flexibility for different testing requirements. It uses an ion selective electrode and supports up to 2 calibration points, along with auto standard recognition, changeable high and low calibration values, multiplication compensation, and temperature calibration for practical day-to-day operation. Auto hold and auto stable modes help users capture readings more easily, while switchable backlight, automatic power off, low battery indicator, IP67 dust and waterproof protection, and replaceable sensor design support reliable portable use. With a clear monochrome LCD and approximately 400 hours of battery life without backlight, LAQUAtwin NO3-11C / NO3-11S / NO3-11 is well suited for direct nitrate and nitrate-nitrogen testing in compact form.

FEATURES

• LAQUAtwin NO3-11 is a pocket nitrate meter designed for direct small-volume nitrate and nitrate-nitrogen testing in field and laboratory applications.
• Measurement principle is based on an ion selective electrode for practical nitrate analysis.
• Minimum sample volume is 0.3 mL, or 0.05 mL when used with Sampling Sheet B, helping reduce sample consumption during testing.
• Nitrate, NO3-, measurement range is 6 to 9900 ppm, mg/L, for broad routine testing capability.
• Nitrate-nitrogen, NO3-N, measurement range is 1.4 to 2200 ppm, mg/L, and 0.7 to 1100 kg/10a.
• Resolution is 1 ppm from 6 to 99 ppm, 10 ppm from 100 to 990 ppm, and 100 ppm from 1000 to 9900 ppm.
• Accuracy is ±10% of actual value for routine nitrate measurement.
• Up to 2 calibration points are supported for practical day-to-day calibration handling.
• Auto standard recognition helps simplify routine calibration setup.
• Changeable high and low calibration values provide added flexibility for different testing needs.
• Temperature calibration supports more controlled measurement handling during routine use.
• Multiplication compensation supports adjusted concentration handling where required.
• Auto hold and auto stable measurement modes help users capture stable readings more easily.
• Switchable backlight supports clearer viewing in different working conditions.
• Automatic power off after 30 minutes helps preserve battery life during routine use.
• Low battery indicator provides clear battery status information.
• IP67 dust and waterproof protection supports use in demanding laboratory and field environments.
• Replaceable sensor supports practical maintenance and continued use.
• Display is a custom monochrome digital LCD with backlight.
• Temperature display range is 0 to 50.0°C.
• Operating conditions are 5 to 40.0°C and 85% or less relative humidity with no condensation.
• Power supply uses 2 × CR2032 batteries.
• Battery life is approximately 400 hours of continuous use without backlight.
• Material is ABS epoxy.
• Dimensions are 164 × 29 × 20 mm, excluding projections.
• Mass is approximately 55 g, including sensor and batteries.
