Electrochemistry Meters & Analysers
Portable pH Meter Kit PH8500-FT with LabSen 373 Flat Electrode for Surface Testing
AUD 995.00(Ex GST)
AUD 995.00(Ex GST)
- Portable pH meter kit designed for professional flat surface pH measurement workflows
- Suitable for skin, paper, textiles, culture medium and other compatible flat surface samples
- Practical choice for surface-contact pH testing where a standard bulb electrode is not ideal
- LabSen® 373 POM-body flat pH/temperature electrode supports direct surface measurement and general water-solution testing
- GLP data management supports measurement storage, calibration records and USB data output for reporting workflows
- Complete kit includes PH8500 Meter, LabSen® 373 Flat pH/Temp Electrode, pH 4.00 / 7.00 / 10.01 Calibration Solutions, USB Cable, Software Flash Drive, User Manual, Carrying Case and Screwdriver
[request_quote_button]
- Description
- Datasheets & Manuals
Description
Portable pH Meter Kit PH8500-FT with LabSen 373 Flat Electrode for Surface Testing, also known as a flat surface pH meter kit, is designed for professional pH measurement on compatible flat surface samples. This kit is suitable for skin, paper, textiles, culture medium and other compatible surface-testing applications. It can also be used for general water-solution pH measurement where the sample and electrode contact method are suitable.
The supplied LabSen® 373 POM-body 3-in-1 Flat pH/Temperature Electrode is designed for direct surface pH measurement. Its flat glass membrane helps provide contact on surfaces where a conventional bulb-style pH electrode may not be practical.
The electrode includes a PTFE ring junction, POM electrode body, blue gel inner solution and long-life reference system. These design features support stable measurement and practical handling in suitable flat surface testing workflows. The PH8500 meter includes GLP standard data management with 500 data sets of storage, manual or automatic storage and USB data output. This supports measurement review, reporting and routine documentation for laboratory and QC workflows.
The meter also supports automatic calibration, self-diagnosis, electrode slope display, auto power-off and easy parameter setting. The large backlit LCD shows pH, temperature, stability status, calibration icons, time and storage information. The IP57 waterproof rating, soft silicone case and foldable stand make the meter suitable for handheld use and benchtop-style laboratory operation.
Included with this Portable pH Meter Kit: User Manual, Carrying Case, USB Cable, Software Flash Drive, Screwdriver, PH8500 Meter, pH 10.01 Calibration Solution, pH 7.00 Calibration Solution, pH 4.00 Calibration Solution and LabSen® 373 Flat pH/Temp Electrode.
Users should follow correct calibration, rinsing, cleaning and electrode storage procedures to support stable readings and electrode service life. For flat surface testing, surface moisture condition and consistent electrode contact are important for reliable measurement.
LabChoice Australia supplies flat surface pH meter kits for laboratories, schools, universities, QC teams, research users, textile testing, surface testing and routine pH measurement workflows.
Features
- PH8500-FT portable pH meter kit
- Designed for flat surface pH measurement
- Equipped with Swiss LabSen® 373 POM-body 3-in-1 flat pH/temperature electrode
- Suitable for skin, paper, textiles and culture medium testing
- Also suitable for general water solutions
- Flat glass membrane
- PTFE ring junction
- POM electrode body
- Blue gel inner solution
- Long-life reference system
- Swiss patented pH/temperature combination structure
- GLP standard data management
- 500 data sets of storage
- Manual data storage
- Automatic data storage
- USB data output
- Automatic calibration
- 1–3 point pH calibration
- Automatic recognition of pH standards: 1.68, 4.00, 7.00, 10.01 and 12.45
- Self-diagnosis for out-of-range values and electrode invalidation
- Electrode slope display
- Auto power-off function
- Easy parameter setting
- Large backlit LCD display
- Stability icon for stable readings
- Finished calibration icons
- Simultaneous temperature display
- Time display
- Manual storage icon and number display
- IP57 waterproof rating
- Soft silicone case for firm and comfortable grip
- Powered by AA batteries
- Foldable stand for benchtop-style use
- Includes PH8500 meter
- Includes LabSen® 373 Flat pH/Temp Electrode
- Includes pH 10.01 calibration solution
- Includes pH 7.00 calibration solution
- Includes pH 4.00 calibration solution
- Includes USB cable
- Includes software flash drive
- Includes user manual
- Includes carrying case
- Includes screwdriver
- Calibration routine, surface moisture condition, electrode contact method, USB data workflow, cleaning method and storage procedure should be confirmed before use
| Technical Specs | ||
|---|---|---|
| pH | Range | -2.00 to 16.00 pH |
| Resolution | 0.01/0.1 pH | |
| Accuracy | ±0.01 pH ±1 digit | |
| Temperature Compensation | 0 to 100°C (Auto or Manual) | |
| mV | Range | -1000 mV – 0 – 1000 mV |
| Resolution | 1 mV | |
| Accuracy | ±0.2% F.S ±1 digit | |
| Temp. | Range | 0 to 100°C (23 to 212°F) |
| Resolution | 0.1°C | |
| Accuracy | ±0.5°C ±1 digit | |
| . | ||
| Other Specs | ||
| Data Storage | 500 sets | |
| Storage Content | Numbering, date, time, measurement, unit, temperature | |
| Output | USB | |
| Power | AA Batteries * 3 / DC5V (USB port) | |
| IP Ranking | IP57 dust-proof and waterproof | |
| Dimensions & Weight | Meter: (88_170_33 ) mm/ 313g With case_(360_270_76) mm/ 1.6kg | |
| . | ||
| pH Electrode (LabSen 373) Specs | ||
| Housing Material | POM | |
| Temperature sensor | Yes | |
| Junction | PTFE ring | |
| Reference Electrode | Long-Life Reference System | |
| Electrolyte | 3M KCL | |
| Shape of glass membrane | Flat | |
| Range | 0 to 14 pH | |
| Temperature Range | 0 to 80°C (32 to 176°F) | |
| Connector | BNC and RCA |
Datasheets & Manuals
Document :
Product Information Sheet(Pdf)
